Carbon Steel Heat Exchanger Tube,Heat Exchanger Alloy Steel Tube ,Stainless Steel Heat Exchanger Seamless Tube
Heat Exchanger Tube
Heat Exchanger Tube
Heat Exchanger Tube
Heat Exchanger Tube
Heat Exchanger Tube

Heat Exchanger Tube

Pipe Type:Carbon Steel Heat Exchanger Tube,Heat Exchanger Alloy Steel Tube ,Stainless Steel Heat Exchanger Seamless Tube

Outside Diameter:6.00 mm to 101.40 mm

Wall Thickness:0.89 mm to 6.00 mm

Length:Up to 30mtr long

Grades:TP-304, 304L, 304H, 304N, 304LN 316, 316L, 316H, 316Ti, 316N, 316LN, 310, 317, 317L, 321, 321H, 347, 347H;UNS S 31260, 31500, 31803, 32205, 32304, 32750, 32760;TP- 405, 410;A179;A192;T1a;Gr.A-1, Gr.C;T5, T9, T11, T12, T22, T91;Gr.1, Gr. 3, Gr.6;P5, P9, P11, P12, P91;Gr.C2;St35.8, St45.8, 15Mo3, 10CrMo9 10;P195GH, P235GH, 16Mo3, 10CrMo5-5, 13CrMo4-5;09CrsuSb (ND Tube)

Standard:ASTM, ASME, DIN EN, JIS ( JAPAN ), NF ( AFNOR );ASTM A179,ASTM A192,ASTM A209,ASTM A210,ASTM A213,ASTM A334,ASTM A335,ASTM A556,DIN 17175,EN 10216,GB 150.2-2011;

Applications :LP / HP Heaters Fertilizer Power Plant Petrochemical & Refinery Airfin Cooler Oil & Gas Sectors

  • Description
  • Specification
  • Production process
  • Packaging pictures
  • Inquiry
Description

Pipe Type:Carbon Steel Heat Exchanger Tube,Heat Exchanger Alloy Steel Tube ,Stainless Steel Heat Exchanger Seamless Tube

Outside Diameter:6.00 mm to 101.40 mm

Wall Thickness:0.89 mm to 6.00 mm

Length:Up to 30mtr long

Grades:TP-304, 304L, 304H, 304N, 304LN 316, 316L, 316H, 316Ti, 316N, 316LN, 310, 317, 317L, 321, 321H, 347, 347H;UNS S 31260, 31500, 31803, 32205, 32304, 32750, 32760;TP- 405, 410;A179;A192;T1a;Gr.A-1, Gr.C;T5, T9, T11, T12, T22, T91;Gr.1, Gr. 3, Gr.6;P5, P9, P11, P12, P91;Gr.C2;St35.8, St45.8, 15Mo3, 10CrMo9 10;P195GH, P235GH, 16Mo3, 10CrMo5-5, 13CrMo4-5;09CrsuSb (ND Tube)

Standard:ASTM, ASME, DIN EN, JIS ( JAPAN ), NF ( AFNOR );ASTM A179,ASTM A192,ASTM A209,ASTM A210,ASTM A213,ASTM A334,ASTM A335,ASTM A556,DIN 17175,EN 10216,GB 150.2-2011;

Applications :LP / HP Heaters Fertilizer Power Plant Petrochemical & Refinery Airfin Cooler Oil & Gas Sectors



Specification
Chemical Composition for ASTM A213 Seamless Steel Tube:
Steel Grade
C Mn P S Si Cr Mo V
ASTM A213 T5 Max: 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 Max: 0.50 4.00 - 6.00 0.45 - 0.65  --
ASTM A213 T9 Max: 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 0.25 - 1.00 8.00 - 10.00 0.90 - 1.10 --
ASTM A213 T11 0.05 - 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 0.50 - 1.00 1.00 - 1.50 0.44 -0.65 --
ASTM A213 T12 0.05 - 0.15 0.30 - 0.61 Max: 0.025 Max: 0.025 Max: 0.50 0.80 - 1.25 0.44 - 0.65 --
ASTM A213 T22 0.05 - 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 Max: 0.50 1.90 - 2.60 0.87 - 1.13 --
ASTM A213 T91 0.08 - 0.12 0.30 - 0.60 Max: 0.020 Max: 0.010 0.20 - 0.50 8.00 - 9.50 0.85 - 1.05 0.18 - 0.25
Cb: 0.06 - 0.1 N: 0.030 - 0.070 Ni: Max: 0.40 Al: Max0.04 Ti: Max: 0.01 Zr: Max 0.01

Mechanical Property for ASTM A213 Seamless Steel Tube:
Steel Grade Tensile Strength, Mpa Yield Strength, Mpa Elongation, %
ASTM A213 T5 Min: 415 Min: 205 Min: 30
ASTM A213 T9 Min: 415 Min: 205 Min: 30
ASTM A213 T11 Min: 415 Min: 205 Min: 30
ASTM A213 T12 Min: 415 Min: 205 Min: 30
ASTM A213 T22 Min: 415 Min: 205 Min: 30
ASTM A213 T91 Min: 415 Min: 415 Min: 20
Production process

Packaging pictures

Inquiry

If you have any inquiries and questions, please contact CONTINENTAL STEEL CO.,LTD. at any time. Thanks in advance. Welcome!

Send Email
Specification
Chemical Composition for ASTM A213 Seamless Steel Tube:
Steel Grade
C Mn P S Si Cr Mo V
ASTM A213 T5 Max: 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 Max: 0.50 4.00 - 6.00 0.45 - 0.65  --
ASTM A213 T9 Max: 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 0.25 - 1.00 8.00 - 10.00 0.90 - 1.10 --
ASTM A213 T11 0.05 - 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 0.50 - 1.00 1.00 - 1.50 0.44 -0.65 --
ASTM A213 T12 0.05 - 0.15 0.30 - 0.61 Max: 0.025 Max: 0.025 Max: 0.50 0.80 - 1.25 0.44 - 0.65 --
ASTM A213 T22 0.05 - 0.15 0.30 - 0.60 Max: 0.025 Max: 0.025 Max: 0.50 1.90 - 2.60 0.87 - 1.13 --
ASTM A213 T91 0.08 - 0.12 0.30 - 0.60 Max: 0.020 Max: 0.010 0.20 - 0.50 8.00 - 9.50 0.85 - 1.05 0.18 - 0.25
Cb: 0.06 - 0.1 N: 0.030 - 0.070 Ni: Max: 0.40 Al: Max0.04 Ti: Max: 0.01 Zr: Max 0.01

Mechanical Property for ASTM A213 Seamless Steel Tube:
Steel Grade Tensile Strength, Mpa Yield Strength, Mpa Elongation, %
ASTM A213 T5 Min: 415 Min: 205 Min: 30
ASTM A213 T9 Min: 415 Min: 205 Min: 30
ASTM A213 T11 Min: 415 Min: 205 Min: 30
ASTM A213 T12 Min: 415 Min: 205 Min: 30
ASTM A213 T22 Min: 415 Min: 205 Min: 30
ASTM A213 T91 Min: 415 Min: 415 Min: 20
Production process

Packaging pictures

Inquiry
