Pipe Type:Carbon steel Plate,Steel Plate,Cold rolled steel plate ,Hot Rolled Carbon Steel Plate,Carbon Steel Sheet Plate
Thickness: 0.1mm-5000mm，etc
Width : 0.5mm-2.5m，etc
Length: 1m-12m,or customized
Technique: Hot roll, cold roll, cold drawn, ect.
Material: A106A-B、08F、T7、T12A、T8Mn、DR510-50、DRI750G-35、25CrMoVA、30CrMnSi、 50CrVA、4CrW2Si、SS400、A36、SM400A、St37-2、SA283Gr、S235JR、S235J0、S235J2、08AL,SPCC,SPCD,SPCE,SPCEN,ST12,ST13,ST14,ST15,ST16,DC01,DC03,DC04,DC05,DC06,SS400-SS540 Series,S235JR-S355JR Series,ST Series,A36-A992 Series,Gr50 Series,etc.
| Chemical Composition | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Grade | C | Si | Mn | Cu | Ni | Cr | Mo | P | S |
| 14Cr1MoR | ≤0.17 | 0.50~0.80 | 0.40~0.65 | ≤0.30 | ≤0.30 | 1.15~1.50 | 0.45~0.60 | ≤ 0.020 | ≤ 0.010 |
| 12Cr2Mo1R | 0.08~0.15 | ≤0.50 | 0.30~0.60 | ≤0.20 | ≤0.30 | 2.00~2.50 | 0.9~1.1 | ≤ 0.020 | ≤ 0.010 |
| 15CrMoR | 0.08~0.18 | 0.15~0.40 | 0.40~0.70 | ≤0.30 | ≤0.30 | 0.80~1.20 | 0.45~0.60 | ≤ 0.025 | ≤ 0.0 |
Carbon Steel Sheet Thickness Tolerance
| Thickness | 1000 mm wide sheet metal | 1250 mm wide sheet metal |
|---|---|---|
| 0.6 to 0.79 | 0.05 | 0.05 |
| 0.8 to 0.99 | 0.055 | 0.06 |
| 1.0 to 1.19 | 0.06 | 0.07 |
| 1.2 to 1.49 | 0.07 | 0.08 |
| 1.5 to 1.99 | 0.08 | 0.09 |
| 2.0 to 2.49 | 0.09 | 0.1 |
| 2.5 to 2.99 | 0.11 | 0.12 |
| 3.0 to 3.99 | 0.13 | 0.14 |
Carbon Steel Plate Thickness Chart
|
Nominal Size Thickness (inches) |
Weight (lb/ft2) |
|---|---|
| 3/16 | 7.65 |
| 1/4 | 10.2 |
| 5/16 | 12.8 |
| 3/8 | 15.3 |
| 7/16 | 17.9 |
| 1/2 | 20.4 |
| 9/16 | 22.9 |
| 5/8 | 25.5 |
| 11/16 | 28.1 |
| 3/4 | 30.6 |
| 13/16 | 33.2 |
| 7/8 | 35.7 |
| 1 | 40.8 |
| 1 1/8 | 45.9 |
| 1 1/4 | 51.0 |
| 1 3/8 | 56.1 |
| 1 1/2 | 61.2 |
| 1 5/8 | 66.3 |
| 1 3/4 | 71.4 |
| 1 7/8 | 76.5 |
| 2 | 81.6 |
| 2 1/8 | 86.7 |
| 2 1/4 | 91.8 |
| 2 1/2 | 102 |
| 2 3/4 | 112 |
| 3 | 122 |
| 3 1/4 | 133 |
| 3 1/2 | 143 |
| 3 3/4 | 153 |
| 4 | 163 |
| 4 1/4 | 173 |
| 4 1/2 | 184 |
| 5 | 204 |
| 5 1/2 | 224 |
| 6 | 245 |
| 6 1/2 | 265 |
| 7 | 286 |
| 7 1/2 | 306 |
| 8 | 326 |
| 9 | 367 |
| 10 | 408 |
If you have any inquiries and questions, please contact CONTINENTAL STEEL CO.,LTD. at any time. Thanks in advance. Welcome!
